C61 Electro Hydraulic Single Arm Open Die Forging HammerC61 Electro Hydraulic Single Arm Open Die Forging Hammer

Introduction of C type forging hammer:

C61 series single arm electro hydraulic forging hammer is a open die forging hammer that adopt hydraulic pressure-nitrogen gas driven. Upper chamber of hammer rod piston is nitrogen gas, lower chamber is hydraulic oil. It can realize hitting by controlling the oil of lower chamber. It is used all kinds of open die forging.

Advantages of C type forging hammer:

  • Large operation space, high forging precision ,long hammer rod life
  • Compared with steam hammer and air compressor hammer, energy conservation and environment protection
  • Low failure rate, it can realize stop hammer any position

Technical parameters of C type forging hammer:

Item

Unit

C61-30
(1T)

C61-70
(2T)

C61-105
(3T)

C61-140
(4T)

C61-175
(5T)

C61-210
(6T)

C61-280
(8T)

C61-350
(10T)

C61-420
(12T)

Rated hit

energy

KJ

30

70

105

140

175

210

280

350

420

Weight of

falling parts

kg

1300

2600

4000

4800

5500

6300

8000

10500

12500

Max.stroke

mm

1000

1260

1450

1700

1800

1900

2000

2100

2200

Hit frequency

min-1

50-58

65-75

50-58

50-60

48-55

50-55

46-50

46

46

Motor power

kw

45×2

55×3

55×4

55×5

75×5

75×6

75×7

75×11

75×12

Guide rail

space

mm

480

560

600

600

700

800

1000

1100

1100

Operating

Spaces

mm

730×

1750

840×

2150

960×

2340

960×

2500

1250×

2200

1300×

2300

1400×

2400

1450×

2500

1450×

2500

Lower die

suface height

mm

750

750

750

750

760

760

780

850

900

Outslde size
(L×W×H)

mm

3800×

1680×

7000

4260×

1800×

7200

4700×

1900×

7600

5440×

1900×

8000

5700×

2300×

8500

5850×

2400×

8700

6400×

2600×

9200

6400×

2600×

9300

6400×

2600×

9400
